Top Feed Vibroflot with High Centrifugal Force Adjustable Speed and Large Amplitude for Vibro Compaction

Top Feed Vibroflot with High Centrifugal Force Adjustable Speed and Large Amplitude for Vibro Compaction

Nombre De La Marca: BVEM
Número De Modelo: BJVE 426-180、BJVE 450-260
Cuota De Producción: 1 juego
Detalles Del Embalaje: caja de madera
Condiciones De Pago: LC, T/T
Información detallada
Lugar de origen:
Porcelana
Certificación:
CE、ISO
Condición:
NUEVO
Peso:
2320 kilogramos, 3280 kilogramos
Potencia del motor:
180 kilovatios, 260 kilovatios
Dimensión (largo* ancho* alto):
3020*676*440 mm, 3310*700*450 mm
Garantía:
1 año o 2000 horas (lo que ocurra primero)
Color:
Verde
Aplicación:
Compactación vibro, reemplazo vibro
MOTOR:
300 kilovatios/400 kilovatios
Tipo de potencia:
Eléctrico
Max. Amplitud:
22mm, 26mm
Máx. Velocidad:
1450 r/min
Corriente nominal:
380A
Fuerza centrífuga:
280 kN, 440 kN
Capacidad de la fuente:
600 juegos/año
Resaltar:

High Centrifugal Force Top Feed Vibroflot

,

Adjustable Speed Vibroflotation Equipment

,

Large Amplitude Vibro Compaction Equipment

Descripción del producto
Comparative Analysis of Vibroflotation Equipment Series 1
In the field of vibroflotation equipment, products of different technical types and models exhibit significant differences in performance parameters and application scenarios. This analysis compares four vibroflotation equipment models—BJVE-426-180 (conventional electric), BJVE-450-260 (conventional electric), BJVH-350-150 (hydraulic), and BJVEF-450-225 (electric variable-frequency)—to provide professional references for equipment selection decisions.
Main Parameter Comparison
Vibro Model Electric Normal
BJVE-426-180
Electric Normal
BJVE-450-260
Hydraulic
BJVH-350-150
Electric Frequency Conversion
BJVEF-450-225
Diameter (mm) 426 450 350 450
Power (kW) 180 260 150 225
Speed (rpm) 1450 1450 2600-2900 1450-1740
Centrifugal Force (kN) 280 440 250-350 520
Max. Amplitude (mm) 22 26 11 20
Comparison of Core Parameters: From Specifications to Power Performance
1. Differences in Basic Specifications
Diameter: The diameters of the four models vary significantly, ranging from 350mm (BJVH-350-150) to 450mm (BJVE-450-260 and BJVEF-450-225), with the BJVE-426-180 measuring 426mm. Diameter directly affects the equipment's adaptability to the operating environment. Larger-diameter equipment offers a wider deep vibration influence range and compaction scope, while smaller-diameter models provide stronger penetration, greater flexibility, and produce smaller pile diameters.
Power: Power ranges from 150kW (BJVH-350-150) to 260kW (BJVE-450-260). The electric variable-frequency model BJVEF-450-225 has a power of 225kW, and the conventional electric model BJVE-426-180 has 180kW. Power determines the equipment's vibration output capacity and continuous operating intensity.
2. Power and Vibration Performance
Speed: Conventional electric models BJVE-426-180 and BJVE-450-260 have a fixed speed of 1450rpm, classified as constant-speed vibroflotation equipment. They are mostly used in common soft soil foundation treatment projects.
The electric variable-frequency model BJVEF-450-225 features adjustable speed (1450-1740rpm), allowing flexible adjustment of vibration frequency according to operational needs. It is suitable for soft foundations with shallow hard soil layers.
The hydraulic model BJVH-350-150 has a wide speed range (2600-2900rpm). Its high speed enables faster vibration frequency, making it suitable for complex hard soil layers.
Centrifugal Force: Centrifugal force is the core embodiment of the equipment's "exciting force". The BJVEF-450-225 leads significantly with 520kN, followed by the BJVE-450-260 (440kN), the BJVH-350-150 (250-350kN range), and the BJVE-426-180 (280kN). High centrifugal force means the equipment can more efficiently handle high-resistance, high-load vibration operations (such as deep foundation compaction and penetration capacity in hardness soil layer).
Maximum Amplitude: Amplitude determines the "influence width" of vibration. The BJVE-450-260 has the largest amplitude at 26mm, followed by the BJVE-426-180 (22mm), the electric variable-frequency model BJVEF-450-225 (20mm), and the hydraulic model BJVH-350-150 (only 11mm). Equipment with large amplitude provides a larger radius of influence on soil compaction around the vibration area during foundation compaction construction.
