Vibroflot hidráulico
>
Hydraulic Vibroflot with 220 kN Centrifugal Force 20 m³/min Air Compressor and 500-800 mm Diameter for High Compaction Efficiency

Hydraulic Vibroflot with 220 kN Centrifugal Force 20 m³/min Air Compressor and 500-800 mm Diameter for High Compaction Efficiency

Nombre De La Marca: BVEM
Número De Modelo: BJVH-350-150
Cuota De Producción: 1
Precio: 35000 $
Detalles Del Embalaje: caja de madera
Condiciones De Pago: LC, T/T
Información detallada
Lugar de origen:
PORCELANA
Certificación:
CE、ISO 9001:2000、ISO 9001:2008
Compresor de aire:
20 M3/min
Tipo:
Hidráulico
Solicitud:
mejora de suelo
Método:
Vibrocompactación o Reemplazo
Diámetro de la pila:
500-800 milímetros
Potencia Vibroflot:
150kw
longitud del vibrador:
2250 milímetros
Paquete de poder:
176 kilovatios
Diámetro exterior:
350 mm
Sistema de control:
Mando a distancia
Fuerza centrífuga de vibración:
220 kN
Capacidad de la fuente:
600 juegos/año
Resaltar:

Hydraulic Vibroflot with 220 kN centrifugal force

,

Hydraulic Vibroflot with 20 m³/min air compressor

,

Hydraulic Vibroflot for high compaction efficiency

Descripción del producto
Hydraulic Vibroflot with 220 kN Centrifugal Force
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified
Product Overview

With over 50 years of dedication to the vibroflotation industry, BVEM has focused on R&D and investment in vibroflotation products. Our BJVH-350-150 hydraulic vibroflot represents the culmination of technical expertise and innovation, delivering high-efficiency, stable performance for demanding vibroflotation projects.

Working Principle

This hydraulic vibroflot efficiently converts hydraulic energy into mechanical energy (rotational motion) through a hydraulic motor, driving the eccentric block to generate strong horizontal excitation force. Key advantages include:

  • Large output torque for demanding applications
  • Wide speed regulation range with stepless control
  • Excellent impact load resistance
  • Stable power output for consistent performance
Key Features
  • 0-2900rpm stepless speed regulation: Flexible operation matching various construction requirements and soil conditions
  • Wide stratum compatibility: Optimized design provides strong penetration in both soft soil and gravel-containing strata
  • Continuous high-power output: Ensures stable operation and improved project efficiency
  • Water-cooled motor not required: Enables dry method environmental protection construction
  • High adaptability: Compatible with various equipment including pump stations, rotary drilling rigs, excavators, and pile frames
Certifications
CE Certified ISO 9001 Made in China
Applications

The BVEM Hydraulic Vibroflot (Model: BJVH-350-150) is designed for soil improvement across multiple construction scenarios:

  • Foundation Construction: Compacts soil to ensure stable building foundations
  • Road and Highway Projects: Enhances soil strength and reduces settling for durable infrastructure
  • Retaining Wall Installation: Improves soil stability and prevents erosion
Technical Evolution

BVEM has pioneered advancements in vibroflot technology, including:

  • Transition from electric to hydraulic driving systems
  • Development of both orifice filling and bottom discharge models
  • Expansion of mounting scenarios for diverse construction needs

This equipment provides contractors and engineers with a reliable, high-performance solution for soil improvement projects, combining quality construction with operational efficiency.
